Published on September 7, 2017

Cevotec presents extended Fiber-Patch-Placement-based production systems at CAMX and Composites Europe Stuttgart

Cevotec presents extended Fiber-Patch-Placement-based production systems at CAMX and Composites Europe Stuttgart

Cevotec presents extended Fiber-Patch-Placement-based production systems at CAMX and Composites Europe Stuttgart

Cevotec presents extended range of applications of Fiber Patch Placement technology at Composites and Advanced Materials Expo (CAMX, September 11.-14.) and Composites Europe Stuttgart (September 19.-21.): Besides high-volume production systems with a capacity of 100 kg per hour, a special, low-investment version for R&D departments and low-volume production is planned. Also, the processing of prepreg material is in preparation.

Following the successful market launch of the Fiber Patch Placement system SAMBA and the matching software ARTIST STUDIO, Cevotec has initiated the next development steps. Until now, the SAMBA system focused on the production of complex 3D preforms with a design space of about one cubic meter, but the attention of the Cevotec engineers is now directed to larger dimensions. “Fiber Patch Placement as a manufacturing concept is almost arbitrarily scalable,” emphasizes Felix Michl, CTO of Cevotec. For high-volume production with Fiber Patch Placement technology, production cells will be able to process 15 kg of fiber material per hour. Integrated in a production line with several cells, the capacity, even while working on highly complex components, increases to more than 100 kg per hour – per request also as hybrid systems processing carbon- and glass fiber simultaneously.

Tailored to the requirements of development departments, research facilities and smaller serial productions, a special SAMBA version produces patch-based preforms in lower quantities. This allows for a low-investment entry into the patch technology and enables developers to continuously work on components without occupying precious production time of a series production system. The price for this system starts below 150.000 Euro.

Cevotec is also working on a new system type that will enable manufacturers to process pre-impregnated fibers such as M21 material on the basis of Fiber Patch Placement technology. “When processing dry fibers, the patch gripper heats up the bindered patches before placing them on the mold”, explains Felix Michl. “When working with prepreg patches, the substrate or the mold is pre-heated at the position where the next patch is to be applied.” This version of SAMBA is intended to primarily meet the requirements of the aerospace industry, which also benefits from the very accurate fiber positioning and the excellent mechanical properties of patch laminates.

Cevotec at CAMX
CAMX Award Pavilion and Stand R92
Cevotec at Composites Europe Stuttgart
Hall 4, booth C 75

About Cevotec
Cevotec offers smart production technology for fiber composites based on Fiber Patch Placement technology, enabling manufacturers to build complex parts fully automated in high volumes and quality. SAMBA is Cevotec’s high-tech preforming system for challenging 3D geometries and laminates with complex fiber orientation. With ARTIST STUDIO, Cevotec provides the matching CAD-CAM software platform and, in addition, offers development services for prototypes and series products. Cevotec is a spin-off from Technische Universität München and partners with Airbus Group, Baumann Automation and the European Space Agency ESA to industrialize the production of complex composites.

Further information: http://www.cevotec.com.
